Ball Systems designed, built, and validated a fully automated production test system that exercises the Gen5/6 Transmission Control Modules across their complete electrical and communication interface, including from analog and digital I/O through CAN bus and relay-switched load simulation.

The system is built around an 18-slot, 3U PXI/PXIe chassis, with scope of supply spanning hardware design, mechanical and electrical documentation, and custom National Instruments (NI) LabVIEW test software. Each unit ships internationally in a purpose-built crate, backed by an uninterruptible 5kVA power supply for continuous, protected test operation.

System Specification

This system is built on a PXI/PXIe platform housed in an 18-slot, 3U chassis, sized to support the full instrumentation and switching load without compromising airflow or serviceability. Custom LabVIEW software drives the test sequencing, giving the customer a platform that's both robust out of the box and straightforward to modify as requirements evolve. Communication is handled over CAN and RS-422/485, matching the protocols already in use on the unit under test. At the same time, a PXIe relay matrix manages signal switching with the density and reliability high-mix testing demands. A 5kVA UPS keeps the system running clean through power events, and the unit ships internationally in a protective crate, built to arrive ready to install — not ready to repair.

Scope of Supply
